Industrial Check Weighing Machine for Pharma

The industrial check weighing machine for pharma is engineered for precision and regulatory compliance, ensuring every blister pack, bottle, vial, or capsule meets strict weight tolerance standards. This industrial check weighing machine for pharma supports FDA and 21 CFR Part 11 requirements and offers full data traceability, cleanroom‑safe materials, and automatic rejection of out‑of‑tolerance packs. Key FeaturesHigh visibility 10inch TFT screen with a graphic user interfaceAutomatic weighing compensation and zero trackingAutomatic measuring time adjustmentBag or case weighing up to 100gEasy integration in almost every production lineExcellent accuracy, especially with flexible packaging1,000,000pcs weight value for production statisticsData storage and data printout readyVariable belt speed controlDesigned for the control of packaged and unpackaged goodsStatistics programs for evaluation

Applications

Blister / Strip Packs
Capsules & Tablets
Bottles & Syrups
Vials / Ampoules
R&D / QA Test Labs
  Technical Specifications
Technical Specifications
Model GBCW -100g
Scale Division 0.05g
Weighing range 5~100g
Accuracy ±0.2g
Weighing speed 160pcs/min
Belt speed 5-90meter/min
Platform size 275x133mm
Height 830±50mm
Belt size 250x100mm
Belt material PU (White)
Belt thickness 0.7mm
Tested object size 50-180×20-80×10-150mm
Display size 10 inch
Alarm light 3-color signal light
Alam horn Optional
Holder/Frame material 304 stainless steel
Weigher platform material 304 stainless steel
Data storage   100 sets of parameters and 1 million weighing results
Communication RS485 (Modbus RTU)/Modbus TCP/IP
Rejection mechanism Swing ~ arm type, Flap type
Air pressure 0.4~0.6 MPa
Segment 3 levels
IP grade IP54A27:B50
